Description
Specification
|
Iterm
|
Type
|
Details
|
Descriptions
|
|||||
|
Physical Standard Configuration
|
Product Form
|
Form Factor
|
IP68 Rugged Tablet PC
|
|||||
|
Dimensions
|
291.4*178.8*17mm
|
|||||||
|
Weight
|
0.95KG
|
|||||||
|
LCD
|
Screen Size
|
8/10.1″
|
||||||
|
Screen Resolution
|
1200*1920
|
|||||||
|
Brightness
|
400nit
|
|||||||
|
TP
|
Touch Module
|
G+G Multi-Touch
|
||||||
|
Battery
|
Type
|
Rechargeable lithium polymer
|
||||||
|
Capacity
|
8500/10000mAh/3.7V
|
|||||||
|
Working Time
|
Over 8 hours (FHD local video display)
|
|||||||
|
Hardware Configuration
|
CPU
|
Type
|
MT6762 Eight-core 1.70GHz
|
MTK6753 Eight-core 1.30GHz
|
Intel Cherry Trail x5-Z8350 Quad-Core 1.44GHz ~ 1.92GHz
|
|||
|
GPU
|
Type
|
Mali-T760MP2
|
Mali-T720MP3
|
Intel HD Graphics Gen8
|
||||
|
OS
|
version
|
Android 7/9/10
|
Windows OS/Linux
|
|||||
|
Memory
|
Capacity
|
4GB
|
||||||
|
Storage
|
eMMC
|
64GB
|
||||||
|
Camera
|
Front
|
5MP
|
||||||
|
Rear
|
13MP
|
|||||||
|
Speaker
|
Built-in
|
8Ω/1W with water proof
|
||||||
|
Micphone
|
Built-in
|
Yes
|
||||||
|
G-sensor
|
Built-in
|
Yes
|
||||||
|
Optional
|
NFC
|
Optional
|
||||||
|
Barcode(1D/2D)
|
Optional
|
|||||||
|
Fingerprint
|
Optional
|
|||||||
|
RFID
|
Optional
|
|||||||
|
Network Connections
|
GPS
|
GPS, BD,glonass
|
||||||
|
WIFI
|
WIFI 802.11ac/b/g/n 2.4G&5Ghz Dual-band
|
|||||||
|
2G/3G/4G
|
2G GSM：850/900/1800/1900MHz，3G WCDMA：B1/B2/B5/B8，3G TD-SCDMA：B34/B39，4 G FDD-LTE Band：B1/B3/B4/B5/B7/B8/B12/B17/B20/，EVDO: BCO，4G
TDD-LTE Band：B38/B39/B40 /B41 |
|||||||
|
BT
|
BT4.0
|
|||||||
|
I/O
|
USB
|
Micro USB2.0
|
×1pcs
|
|||||
|
TF Card reader
|
TF Card reader
|
×1pc
|
||||||
|
Audio Jack
|
3.5mm
|
×1pc
|
||||||
|
SIM Card
|
/
|
×1pc
|
||||||
|
OTG
|
/
|
Support
|
||||||
|
Button Switch
|
Power
|
On/Off
|
×1pc
|
|||||
|
Volume
|
Down/UP
|
×1pc
|
||||||
|
Main Accessories
|
Power adapter
|
DC 5V/3A
|
×1pc
|
|||||
|
Cable
|
Micro usb
|
×1pc
|
||||||
|
Handle Straps
|
Optional
|
Optional
|
||||||
|
Environment
|
Temperature
|
Operation Temperature
|
-10oC ~ 55oC
|
|||||
|
Storage Temperature
|
-20oC ~ 70oC (Restore to Operation Temperature 2hr before use)
|
|||||||
|
Humidity
|
Oprating Humidity
|
35% ~ 80% relative humidity, Non-condensing
|
||||||
|
Storage Humidity
|
20% ~ 93% relative humidity, Non-condensing
|
|||||||
